High Rate 23W/cell/15Min Automatic Alarm System UPS Battery 6-GFM-5C

MHB HR series high-rate sealed maintenance-free lead-acid batteries are specially designed for high-performance requirements, with excellent discharge capacity and long service life. Its sealed structure ensures safety and reliability, eliminating daily maintenance worries, and is suitable for various application scenarios such as UPS, power tools, and solar energy storage. Whether it is high load or frequent charging and discharging.

    Features

    1. 1.High rate discharge: Supports high load applications, suitable for frequent charging and discharging scenarios, ensuring stable power output.

    2. 2.Maintenance-free design: The sealed structure eliminates the risk of liquid leakage and eliminates the need for regular maintenance, saving time and costs.

    3. 3.Long lifespan: Using advanced materials and processes to extend battery life and reduce replacement frequency.

    4. 4.Safe and reliable: It has overcharge, over-discharge and short-circuit protection functions to ensure safety during use.

    5. 5.Wide application: Suitable for UPS systems, power tools, solar energy storage and other fields to meet different needs.

    6. 6.Excellent temperature resistance: It can still maintain good performance under extreme temperature conditions and adapt to a variety of environments.

    7. 7.Environmentally friendly materials: Comply with environmental protection standards, no pollution during use, and promote sustainable development.

    Construction

    1.Component.............material
    2.Positive plate.............Lead dioxide
    3.Negative plate.............Spongy lead
    4.Battery case.....ABS Engineering plastics
    5.Safety valve.............Fluorinated rubber
    6.Wire terminal..... Silver-plated copper
    7.Isolation plate..... Ultrafine glass fiber
    8.Electrolyte........ Analytical pure sulfuric
    high rate ups 1223w battery

    Specification

    Battery model HR1223W (23W/cell/15Min)
    Battery life designed more than 3 years in the float charging mode
    Capacity designed
    (25℃)
    20HR(0.262A,10.5V) 10HR(0.496A,10.5V) 5HR(0.891A,10.5V) 1HR(3.034A,10.5V)
    5.240AH 4.960AH 4.455AH 3.034AH
    Battery size Length Width Height Total Height
    90mm 70mm 101 mm 105 mm
    Battery weight 1.83 KG±3%
    Nominal internal resistance 100% charging is completed at 25°C environment≤  31.00 mQ
    Self-discharge rate 2% self-discharge rate per month,at  25° C environment
    Capacity at different
    temperatures (20HR)
    40℃ 25℃ 0℃ -15C
    102% 100% 85% 65%
    Charging voltage
    (25C)
    Circulation mode Floating charge mode
    14.4-15.0V(-30mV/C), Max Charge Current  1.57 A 13.5-13.8V (-20mV/C)

    Advantages

    1.Using high purity electrolytic lead as the active material, excellent charge-discharge performance and very low self-discharge rate,very conducive to storage and use.
    2. Unique design and formula, excellent high-rate discharge performance.
    3.Fully sealed maintenance-free, no need to supplement the electrolyte during use.
    4.The designed service life is more than 3 years under floating charging mode.

      Application

      1. Automatic alarm system: Built-in intelligent monitoring function, real-time monitoring of battery status, and timely alarms to ensure that users can quickly respond to potential problems and ensure equipment safety.

      2. Electrical automatic control system: Equipped with advanced electrical control technology to realize automatic charge and discharge management, optimize battery performance, extend service life, and improve overall system efficiency.

      3. Uninterruptible power supply system: Provide stable power support for key equipment, ensuring that during power outages or power fluctuations, the system can switch seamlessly, maintain continuous operation, and avoid data loss or equipment damage.

      4. Fire control system: Combined with the safety design of the battery, it can be linked with the fire protection system to provide emergency power support to ensure the normal operation of important equipment and systems in emergencies such as fires.

      5. Universal uninterruptible power supply system: Suitable for various industries and application scenarios, providing reliable power guarantee to ensure that equipment can operate normally under any circumstances and improve work efficiency.

      6. Centralized large-scale power system: Suitable for large enterprises or facilities, it can centrally manage and distribute power to ensure efficient use of resources and reduce operating costs.

      7. Distributed small-scale power system: Flexibly adapts to the needs of small equipment and systems, provides efficient and reliable power support, and is suitable for small application scenarios such as homes and offices.

      8. Power tool power system: Provides stable power support for all types of power tools, ensuring the normal operation of the tools under high loads and improving work efficiency and safety.

      Payment & Delivery

      Payment Terms: TT, D/P, LC, OA, etc.
      Delivery Details: within 30-45 days after order confirmed.
