MHB 12V 9Ah UPS Supporting Fire Suppression Safety Lead-Acid Battery 6-FM-9B

Reliable and robust, the UPS Supporting Fire Suppression Safety Lead-Acid Battery is engineered for critical emergency power. Ideal for fire safety systems, it ensures uninterrupted power, long-lasting performance, and dependable support in demanding environments.

product details

Product Tags

Download PDF

Features

Critical Reliability: Engineered specifically for fire suppression systems, providing consistent emergency power when it's needed most.
Extended Service Life: High-quality lead-acid construction supports long-term use, minimizing replacement frequency in fire safety applications.
Enhanced Stability: Optimized for efficient charging and discharging, with low self-discharge rate to ensure readiness for emergencies.
Advanced Safety Protection: Includes safeguards against overcharge, over-discharge, and short circuits, ensuring reliable performance in critical moments.
Low-Maintenance Design: Maintenance-free structure makes it easy to install and manage within fire suppression systems, reducing labor costs.
Wide Operating Temperature Range: Performs dependably in various environments, from -20℃ to 60℃, suitable for diverse fire safety needs.

Construction

1.Component ......Raw material

2.Positive ........Lead dioxide

3.Negative ........Lead

4.Container ........ABS

5.Cover ........ABS

6.Sealant ........Epoxy

7.Safety valve .... Rubber

8.Terminal ........Copper

9.Separator ........Fiber glass

10.Electrolyte .......Sulfuric acid

corporate-wechat-screenshot_17309728822088

Specification

Battery Model	MS9-12 12V8.5AH
Designed Floating Life	3 ~5 Years
Capacity (25℃)	20HR(0.425A,10.5V)	10HR(0.822A,10.5V)	5HR(1.615A,10.5V)	1HR(5.517A,10.5V)
	8.50AH	8.22 AH	8.08 AH	5.52 AH
Dimensions	Length	Width	Height	Total Height
	151 mm	65 mm	94 mm	98 mm
Approx. Weight	2.55Kg ±3%
Internal Resistance	Full charged at 25℃:≤24.50 mQ
Self Discharge	2% of capacity declined per month at (25℃)
Capacity Affected by Temp.(20HR)	40℃	25℃	0℃	-15℃
	102%	100%	85%	65%
Charge Voltage(25oC)	Cycle use		Float use
	14.4-15.0V(-30mV/℃), max.Current:2.70A		13.5-13.8V(-20mV/℃)

Advantages

Dependable Emergency Power: Delivers consistent, uninterrupted power to fire suppression systems, ensuring readiness during power outages.
Enhanced Safety Measures: Equipped with advanced safety features, including overcharge and short-circuit protection, to reduce risks in critical environments.
Long Lifespan: Durable lead-acid design ensures extended battery life, reducing the need for frequent replacements and providing cost efficiency over time.
Ease of Maintenance: Maintenance-free structure simplifies upkeep, making it ideal for large-scale fire safety systems requiring reliable, low-maintenance operation.
Environmental Resilience: Performs reliably across a wide temperature range, suitable for a variety of installation environments.
Cost-Effective Solution: Combines high performance and durability with affordability, providing a practical and budget-friendly option for fire suppression systems.

Application

Fire Alarm Systems: Provides uninterrupted power to fire alarm systems, ensuring timely detection and response during emergencies.
Fire Suppression Systems: Supplies reliable power to fire suppression equipment, including sprinklers and gas-based fire extinguishing systems, during power failures.
Emergency Lighting: Powers emergency lights and exit signs, ensuring safe evacuation paths are illuminated during fires or blackouts.
Smoke Control Systems: Supports smoke control and ventilation systems, helping to maintain clear airways in case of fire emergencies.
Building Safety Systems: Ensures power continuity for essential safety equipment like fire doors, alarms, and monitoring systems in commercial and industrial buildings.
Data Centers: Provides backup power to fire suppression systems in data centers, protecting valuable infrastructure from fire damage.
